GARAGE TYPE

Storage type, PXD


Robot carrier type
Pallet type
Comb tooth type

RENDERING

Rendering


CAD STRUCTURAL DIAGRAM

CAD Structural diagram


Robot carrier type

PARAMETER

Equipment parameters


Project
Robot carrier type
Capacity specifications
Sedan/SUV
Number of vehicles/number of floors that can be made
2-8 floors
Vehicle pick-up time/clearance time
90S
Rated speed
Lift 40-80m/min/Shift 60-100mm/min
Lifting method
Motor+chain type+steel wire rope
Control system
PLC system
Operating mode
IC card/license plate number/facial recognition

OPERATING PRINCIPLE

Operating rinciple


The Weichuang Lane Stacking Machinery Parking Equipment adopts advanced computer control and is a fully automated mechanical parking equipment that integrates mechanical, optical, electrical, and automatic control. Use a stacker crane to move the car horizontally and vertically to the parking space, and use a mechanical arm carrier or access mechanism on the stacker crane to store the car, otherwise remove it.

SIMILAR CASES

Similar cases


RENDERING

Rendering


CAD STRUCTURAL DIAGRAM

CAD Structural diagram


Pallet type

PARAMETER

Equipment parameters


Project
Pallet type
Specifications
Sedan/SUV
Number of vehicles/number of floors that can be made
2-8 floors
Vehicle pick-up time/clearance time
90S
Rated speed
Lift 40-80m/min/Shift 60-100mm/min
Lifting method
Motor+chain type+steel wire rope
Control system
PLC system
Operating mode
IC card/license plate number/facial recognition

OPERATING PRINCIPLE

Operating rinciple


The Weichuang Lane Stacking Machinery Parking Equipment adopts advanced computer control and is a fully automated mechanical parking equipment that integrates mechanical, optical, electrical, and automatic control. Use a stacker crane to move the car horizontally and vertically to the parking space, and use a carrier or access mechanism on the stacker crane to store the car, otherwise remove it.

SIMILAR CASES

Similar cases


RENDERING

Rendering


CAD STRUCTURAL DIAGRAM

CAD Structural diagram


Comb tooth type

PARAMETER

Equipment parameters


Project
Comb tooth type
Specifications
Sedan/SUV
Number of vehicles/number of floors that can be made
2-8 floors
Vehicle pick-up time/clearance time
90S
Rated speed
Lift 40-80m/min/Shift 60-100mm/min
Lifting method
Motor+chain type+steel wire rope
Control system
PLC system
Operating mode
IC card/license plate number/facial recognition

OPERATING PRINCIPLE

Operating rinciple


The Weichuang Lane Stacking Machinery Parking Equipment adopts advanced computer control and is a fully automated mechanical parking equipment that integrates mechanical, optical, electrical, and automatic control. Use a stacker crane to move the car horizontally and vertically to the parking space, and use a comb shaped carrier or access mechanism on the stacker crane to store the car, otherwise remove it.
